Hydraulic wall saw offer high power, precise control, and stable performance. The 600TM model cuts up to 620mm deep, suitable for reinforced concrete, brick, and stone. Compared with standard electric or high frequency wall saws, hydraulic systems are faster for large-scale projects, producing less noise and dust.
Tip: For thick walls or large-scale projects, hydraulic wall saws are typically twice as efficient as standard high frequency wall saws.
Hydraulic Wall Saw Power Station Parameters
| Model | YG-600TM | YG-700TM | YG-600RV |
| Maximum power | 25Kw | 30Kw | 25Kw |
| Motor cooling method | Air cooling | Water cooling | Air cooling |
| Rated voltage | 380V, 50Hz | 380V-420V, 50Hz-60Hz | 380V/400V, 3-phase, 50Hz |
| Pressure stages | 3 | 3 | 3 |
| Max. Operating pressure | 200bar/20Mpa | 210bar/21Mpa | 200bar/20Mpa |
| Oil flow rate | 30-80L/min | 40-100L/min | 30-80L/min |
| Dimension | 600*650*1050mm | 500*520*1100mm | 650*600*1000mm |
| Weight | 220kg | 140kg | 210kg |
Wall Saw Head Parameters
| Model | YG600TM | YG700TM |
| Saw blade diameter range | 800-1400mm | 800-1600mm |
| Cutting depth | 620mm | 730mm |
| Center hole of blade | 60mm | 60mm |
| Saw blade life | Cut 20 square | Cut 20 square |
| Max. working pressure | 180bar/18Mpa | 200bar/20Mpa |
| Max. oil flow rate | 100L/min | 100L/min |
| Gearing | Gear | Gear |
| Rotation speed | 450/900/1350Rpm | 600/850/1400Rpm |
| Dimension(mm) | 400*420*400 | 400*420*400 |
| Weight | 38kg | 39kg |
Wall Saw Features and Technical Advantages
- High-Power Motor: 25–32KW hydraulic motor handles thick concrete with ease.
- Deep Cutting Capacity: 600TM, 700TM, 800TM models reach 620mm and 730mm depth.
- Water Cooling System: Protects blades and prevents motor overheating.
- Remote Control Operation: Wireless operation reduces onsite risks and improves safety.
- Cost Saving: One-pass cutting minimizes structural damage and labor costs.
Tip: Match blades to depth, e.g., 1000mm blade for 40cm deep cutting.
Hydraulic Wall Saw: Wide Application Scenarios
As a professional hydraulic concrete wall saw, hydraulic wall saws serve diverse construction needs:
- Building Renovation: Door/window openings, elevator shaft cutting, staircase modification
- Industrial Construction: Factory concrete wall cutting, pipe channel preparation
- Infrastructure: Bridge and tunnel wall cutting and repair
- Stone Processing: Marble and granite wall cutting, smooth surface guaranteed
Tip: Check wall flatness before cutting to improve precision and extend blade life.
Success Story: UAE Client Case
A UAE contractor used the YG Machinery 700TM hydraulic wall saw for an industrial renovation project. Standard electric wall saws were inefficient and blade wear was high. Using the hydraulic saw:
- Cutting speed increased 2.3×
- Blade life extended 35%
- Project timeline shortened 30%
- Labor cost reduced 25%
The client praised its simplicity and accuracy, ideal for thick concrete walls.
Tip: For thick walls or complex structures, choose 700TM or 800TM models.
Hydraulic Wall Saw Frequently Asked Questions
Reinforced concrete, bricks, stone. Uneven surfaces require a wire saw.
600TM: 620mm, 700TM/800TM: 730mm. For deeper walls, use staged cutting.
Supports three-phase customization. Single-phase is not suitable for hydraulic wall saws. High frequency wall saws support 220V single-phase.
Usually 15–20 sqm per blade, depending on material hardness and cutting frequency.
Choosing a hydraulic wall saw ensures efficient, safe, and cost-effective cutting. For industrial renovations, building upgrades, or heavy concrete cutting, YG Machinery provides hydraulic wall saws, high frequency wall saws, and professional wall saw machines to meet your needs. Contact us today for a quote and technical support.
