A glass lifter machine is used to lift and install large glass panels safely. It reduces up to 60% of manual handling risk in construction projects.
In today’s market, buildings use larger glass panels than before. Manual lifting is no longer safe or stable.
From our YG machinery experience, most buyers face the same issue: heavy glass and slow installation.
That is why glass lifter machine demand is increasing.
Glass Lifter Machine Parameter
| Model Type | YG-LD-300 | YG-LD-400 | YG-LD-500 | YG-LD-600 | YG-LD-800 | |
| Load Capacity | 300kg(retract)150kg(extend) | 400kg(retract)200kg(extend) | 500kg(retract)250kg(extend) | 600kg(retract)300kg(extend) | 800kg(retract)400kg(extend) | |
| Lifting Height | 3500mm | 3500mm | 3700mm | 3700mm | 4500mm | |
| QTY of Suction Cap | 4pcs | 4pcs | 6pcs | 6pcs | 8pcs | |
| Rubber Suction Cap | 300mm | Ø300mm | Ø300mm | Ø300mm | Ø300mm | |
| Maintenance-free Battery | 2x12V/80AH | 2x12V/100AH | 2x12V/120AH | 2x12V/120AH | 2x12V/120AH | |
| Battery Charger | Smart Charger | Smart Charger | Smart Charger | Smart Charger | Smart Charger | |
| Drive motor | 24V/1200W | 24V/1200W | 24V/1200W | 24V/1200W | 24V/1200W | |
| Lifting Motor | 24V/2000W/6L | 24V/2000W/6L | 24V/2000W/6L | 24V/2000W/6L | 24V/2000W/12L | |
| Chassis L*W | 2660*810mm | 2660*810mm | 2800*810mm | 2800*810mm | 2800*810mm | |
| Driving Wheel | Ø250x80mm | Ø250x80mm | Ø300x100mm | Ø300x100mm | Ø300x125mm | |
| Packing Size(mm) | 2560*1030*1700 | 2560*1030*1700 | 2580*1050*1700 | 2580*1050*1700 | 3000*1250*2300 | |
| N.W/G.W | 1100/1150kg | 1280/1330kg | 1300/1350kg | 1400/1450kg | 1600/1650kg | |
| Loading Qty | 1x20GP/40GP: 6SETS/12SETS | |||||
| Movement | Automatic(4 kinds) | 1. The suction cup frame flips 180° electrically. 2. The support plate automatically retracts. 3. Hydraulic arm lifts electrically. 4. The base of the whole machine moves 100-150mm horizontally. | ||||
| Manual (2kinds) | 1. The suction cup holder can be manually rotated 90 degrees (electrically powered optional). 2. The suction cup holder can be manually rotated 360 degrees (electrically powered optional). | |||||
| Usages | Mainly used for the handling, movement, and installation of materials such as glass, marble, wood, iron plate, etc. | |||||
How Does a Glass Lifter Machine Work?
A glass lifter machine uses vacuum pressure to hold glass safely.
Main systems include:
- vacuum suction cups
- hydraulic lifting arm
- rotation system
- safety pressure sensor
- battery powered system
YG machinery models support 300kg to 800kg load. They are also called glass vacuum lifting equipment in the market.
Tip: Stable suction is more important than max load.
Where is the Glass Lifter Machine Used?
Curtain Wall Installation
Curtain wall glass is often over 3 meters.
A glass lifter machine allows 360° rotation and precise positioning.
Many installers also use a glass lifting robot for final alignment.
Marble and Stone Industry
Stone slabs are heavier than glass.
Our Italian customers use it for marble slab handling projects.
Tile and Aluminum Panel Installation
Large format tiles are widely used in modern buildings.
Search demand for glass lifting equipment for sale keeps growing in Europe.
Main reason is lower breakage rate.
Interior and Commercial Projects
Hotels, airports, and malls need precise installation.
Glass lifter machine reduces manual labor needs.
Tip: Indoor projects should choose remote control models.
How to Choose a Glass Lifter Machine?
Check Load Capacity
Common options:
- 300kg
- 400kg
- 500kg
- 800kg
Over 800kg usually needs crane support.
Check Machine Size
Size matters for elevators and doors.
Our 600 model is only 860mm wide.
Check Functions
Recommended features:
- electric rotation
- side tilting
- wireless remote control
These are highly requested in Europe.
Check Working Environment
Indoor and outdoor jobs need different setups.
Wind resistance is important outdoors.
Tip: Windy areas need stronger stabilization systems.
Real Case from Canada
A contractor named Mark from Toronto faced issues:
- unsafe manual lifting
- slow positioning
- frequent glass damage
We provided a glass vacuum lifting equipment 800kg model.
With:
- electric rotation
- wireless control
Results:
- 35% efficiency increase
- fewer workers needed
- lower breakage rate
Later he ordered more units for stone projects.
Glass Lifting Machine FAQ
Yes, with modified suction frame.
tempered glass
insulated glass
marble
granite
tiles
aluminum panels
acrylic sheets
Standard is manual structure.
Optional systems include electric lifting and remote control.
Yes, YG machinery provides full export certification.The
glass lifter machine is changing modern glass installation. It improves safety, speed, and accuracy.
For contractors and factories, it is a key cost-saving solution.
YG machinery offers 300kg–800kg models for global projects.
