Concrete Mixing Plant is a fully integrated construction equipment assembly that integrates six core systems: mixing host system, batching system, storage system, conveying system, weighing system and control system, which can provide stable and standardized concrete output for various construction projects.This equipment has two mainstream host types: compulsory mixer and drum mixer. The compulsory type delivers even mixing for high-grade concrete, while the drum type adapts to low-grade concrete projects with stable operation. We provide flexible configurations including portable concrete batching plant to meet mobile construction demands, and small concrete mixing plant for sale that fits limited-space job sites.
Contact us for a quote.【WhatsApp/WeChat/Phone】+86 13837112713
Core Parameters of Concrete Mixing Plant
| Parameters | YG-25 | YG-60 |
| Model | 25 Station | 60 Station |
| Matching Mixer | YG-500 | YG-1000 |
| Theoretical Output | 25m³/h | 60m³/h |
| Single Discharge Capacity | 0.5m³ | 1.0m³ |
| Feeding Mode | Hoist Lift | Belt Conveyor |
| Batching Bin Quantity | 2-3 bins | 3-4 bins |
| Cement Silo | Customizable | Customizable |
| Control System | Semi-automatic / Full-automatic | Full-automatic with computer printing |
| Weighing System | Aggregate + Cement + Water + Admixture | Independent high-precision weighing |
| Aggregate Conveying | Hoist lifting | Belt conveyor |
| Powder Conveying | Screw Conveyor | Screw Conveyor |
Working Principle of Concrete Mixing Plant
Concrete Mixing Plant completes automatic concrete production through the collaborative operation of six systems. The batching system stores and sorts aggregates; the weighing system accurately measures powder, water and admixtures; the conveying system transfers materials via hoist/belt (aggregates) and screw conveyor (powder); the mixing host stirs materials evenly; the storage system seals powder; the control system centrally manages the whole process to ensure stable and precise output.
Key Advantages of Concrete Mixing Plant
- Dual Host Compatibility：Forced & drum hosts available, covering low-grade and high-grade concrete production needs.
- Flexible & Practical：Compact layout of 25 Station saves space, portable concrete batching plant supports quick transfer; 60 Station with belt feeding delivers higher efficiency.
- Precise Weighing：Multiple weighing modes ensure accurate material ratio, keeping concrete quality consistent.
- Customizable Configurations：Optional batching bins, cement silos and control functions to fit different project requirements.
- Wide Applicability：Small concrete mixing plant for sale fits small projects, 60 Station supports medium-scale commercial and engineering concrete production.
Application Scenarios of Concrete Mixing Plant
This equipment is widely applied to global infrastructure and building construction, including urban residential development, municipal engineering, road and bridge construction, and airport projects. It also supports precast concrete production, commercial concrete supply, rural infrastructure construction, and small on-site construction tasks with flexible adaptability and stable output.
Romania Client Case
This Romanian client is a local infrastructure company focused on rural road and municipal projects. They faced limited site space, unstable concrete quality and discontinuous supply with traditional mixing equipment. We provided a 60 Station Concrete Mixing Plant with automatic control and high-precision weighing system. The equipment was easy to install, ran stably and produced uniform concrete to support continuous construction. The client was satisfied with its performance, which greatly improved project efficiency and concrete quality, and expressed intention for long-term cooperation.
Frequently Asked Questions
1. How to choose the right model?
Select 25 Station for small projects (25m³/h) and 60 Station for medium projects (60m³/h) according to your hourly concrete demand.
2. How many batching bins and cement silos do I need?
2-3 bins for 25 Station, 3-4 bins for 60 Station; cement silo quantity is configured based on your powder material types.
3. Is the computer printing function necessary?
It is recommended for projects needing data recording and quality traceability, can be selected as needed.
Contact YG Machinery for Your Concrete Mixing Plant
YG Machinery is a professional global supplier of Concrete Mixing Plant solutions, with rich export experience and customized configuration capabilities. We provide targeted equipment plans according to your project output, site conditions and application scenarios, supporting global delivery and on-site technical guidance.If you need reliable concrete mixing equipment, contact us now to get a professional customized solution!
